LGX Type 6 Ports SC Fiber Optic Adapter Panel is a standard LGX-compatible adapter plate, supporting 6 SC simplex ports (APC green connectors) for a total of 6 fibers.
It features a snap-in, tool-free design for quick installation into LGX-style fiber patch panels, with APC SC adapters optimized for low back-reflection single-mode applications. The rugged, compact housing ensures stable connections and reliable performance.
Ideal for FTTx, enterprise networks, and data center fiber distribution systems requiring high-precision single-mode connections, it offers a flexible, modular solution for SC-based fiber termination.
| Model | LGX Type 6 Ports SC Fiber Optic Adapter Panel |
| Form Factor | Standard LGX-compatible adapter panel |
| Port Configuration | 6 SC simplex ports (APC green) |
| Installation | Tool-free snap-in design for LGX frames |
| Adapter Type | SC/APC simplex adapters |
| Fiber Compatibility | OS2 single-mode fibers |
| Insertion Loss | ≤0.3dB (SC adapter) |
| Return Loss | ≥60dB (APC) |
| Construction | Rugged black housing, green APC SC adapters |
| Compliance | Compliant with TIA-568-C.3 and IEC 61754-4 standards |
