Tool-free termination, FTP shielded, Cat6 compliant, 180° straight-through design, zinc-alloy shield housing, compatible with T568A/B wiring
No punch-down tool required for faster installation; full metal shielding blocks EMI/RFI; meets Cat6 gigabit performance; fits standard Keystone panels for flexible deployment
Reduces cabling labor costs and on-site errors; ensures stable network transmission in high EMI environments; low signal attenuation over long-term use, supporting enterprise-grade network applications
| Type | Cat6 FTP Tool-free RJ45 Keystone Jack |
| Termination | Tool-free 180° straight-through |
| Performance Grade | Cat6 (Class E), compliant with TIA/EIA-568-C.2 |
| Wire Gauge | 22-26 AWG solid/stranded copper cable |
| Contact Plating | ≥50μ" gold-plated phosphor bronze |
| Shielding | Full FTP metal housing for EMI/RFI protection |
| Wiring Standard | T568A/T568B dual compatible |
| Durability | ≥750 mating cycles for RJ45, ≥100 termination cycles for IDC |
| Electrical Performance | Insulation Resistance ≥500MΩ, Contact Resistance ≤20mΩ |
| Operating Temperature | -40℃ ~ +70℃; Storage Temperature: -40℃ ~ +85℃ |
