Packaged with durable ABS box shell, 2-input & 32-output split configuration pre-terminated with SC/APC 8° angled connectors and G.657 single-mode pigtail. It features outstanding splitting uniformity and low excess loss; APC polish delivers superior return loss against reflection interference, with dustproof enclosure for convenient wiring & storage. Applied for FTTH and PON system distribution, it divides 2 trunk fiber signals into 32 user terminals to simplify network layout and cut total engineering procurement & cabling expense.
| Split Ratio | 2 Input : 32 Output ports |
| Connector Type | SC/APC 8° angled polish connector |
| Fiber Specification | G.657A1 single-mode fiber, 2.0mm yellow loose tube pigtail |
| Operating Wavelength | 1260~1650nm (1310/1490/1550nm compatible) |
| Typical Excess Loss | ≤18.2dB |
| Uniformity Between Ports | ≤1.5dB |
| Return Loss | ≥55dB(APC finished port) |
| Operating Temperature | -40℃ ~ +75℃ |
| Housing Material | High-strength black ABS plastic box |
| Compliance Standard | Conforms to IEC 61300, ITU-T G.657, YD/T 1272, in line with international mainstream PLC splitter industry specifications of Commscope & Corning |
